Fuji 1MBI300U4-120 IGBT Module

Features

· The module should be stored at a standard temperature of 5 to 35°C and humidity of 45 to 75%.

· Store modules in a place with few temperature changes in order to avoid condensation on the module surface.

. Avoid exposure to corrosive gases and dust.

. Avoid excessive external force on the module.

·Store modules with unprocessed terminals.

.Do not drop or otherwise shock the modules when transporting.

Maximum ratings and characteristics

.Absolute maximum ratings (Tc=25°C unless without specified)

Collector-Emitter voltage Vces:1200V

Gate-Emitter voltage VGES:±20V

Collector current Ic Continuous Tc=25°C :300A

Collector current Icp 1ms Tc=25°C :600A

Collector power dissipation Pc:1540W

Isolation Voltage VIsol (AC 1 minute) :2500V

Operating junction temperature Tj:+150°C

Storage temperature Tstg :-40 to +125°C

Mounting screw torque 1.7~3.5 N·m
