Diodes Inc AZ23C3V6-7 IGBT Module

Manufacturer Part Number: AZ23C3V6-7Pbfree Code: NoPart Life Cycle Code: ObsoleteIhs Manufacturer: DIODES INCPart Package Code: SOT-23Package Description: R-PDSO-G3Pin Count: 3ECCN Code: EAR99HTS Code: 8541.10.00.50Manufacturer: Diodes IncorporatedRisk Rank: 5.13Configuration: COMMON ANODE, 2 ELEMENTSDiode Element Material: SILICONDiode Type: ZENER DIODEDynamic Impedance-Max: 95 ΩJESD-30 Code: R-PDSO-G3JESD-609 Code: e0Moisture Sensitivity Level: 1Number of Elements: 2Number of Terminals: 3Operating Temperature-Max: 150 °CPackage Body Material: PLASTIC/EPOXYPackage Shape: RECTANGULARPackage Style: SMALL OUTLINEPeak Reflow Temperature (Cel): 235Polarity: UNIDIRECTIONALPower Dissipation-Max: 0.3 WQualification Status: Not QualifiedReference Voltage-Nom: 3.6 VSubcategory: Voltage Reference DiodesSurface Mount: YESTechnology: ZENERTerminal Finish: Tin/Lead (Sn85Pb15)Terminal Form: GULL WINGTerminal Position: DUALTime Zener Diode, 3.6V V(Z), 5.56%, 0.3W, Silicon, Unidirectional, SOT-23, 3 PIN
