LG Display LC260W01-A5K1 LCD Display

Brand LG.Philips LCD

Diagonal Size 26.0 inch

Pixel Format 1280(RGB)×768  [WXGA]  57PPI

Active Area 566.4(H)×339.84(V) mm

Bezel Area 571.4(H)×344.9(V) mm

Luminance 450 cd/m² (Typ.)

View Direction Symmetry

Viewing Angle 88/88/88/88 (Typ.)(CR≥10)

Support Color 16.7M   72% NTSC

Frame Rate 60Hz

Model LC260W01-A5K1

Type a-Si TFT-LCD , LCM

Configuration RGB Vertical Stripe

Outline Dim. 622(H)×389(V) mm

Treatment Antiglare, Hard coating (3H)

Contrast Ratio 500:1 (Typ.) (TM)

Response Time 7.5/8.5 (Typ.)(Tr/Td)

Operating Mode S-IPS, Normally Black, Transmissive

Light Source CCFL  [14 pcs] , 50K hours , With Inverter

Designed For TV Sets

Touch Panel Without

Interface TypeLVDS (1 ch, 8-bit) , 20 pins Connector

Power Supply12.0V (Typ.)

EnvironmentOperating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C
