#LG, #LM215WF3_SLS2, #LCD_Display, #LCD, LM215WF3-SLS2 LG Display 21.5Inch LCM 1920×1080 250 1000:1 89/89/89/89 16.7M WLED LVDS;
Panel Brand LG Display
Panel Model LM215WF3-SLS2
Panel Size 21.5 inch
Panel Typea-Si TFT-LCD, LCM
Resolution 1920(RGB)×1080, FHD, 102PPI
Pixel Format RGB Vertical Stripe
Display Area 476.064(W)×267.786(H) mm
Bezel Opening 479.8(W)×271.3(H) mm
Brightness 250 cd/m² (Typ.)
Contrast Ratio 1000:1 (Typ.) (TM)
Viewing Angle 89/89/89/89 (Typ.)(CR≥10) Left / Right / Up / Down
Display Mode IPS, Normally Black, Transmissive
Best View on Symmetry
Response Time 14 (Typ.)(G to G)
Display Colors 16.7M 72% NTSC
Lamp Type WLED , 30K hours , Without Driver
Frequency 60Hz
120Hz (60HZ Input) : Embedded MEMC Circuit
120Hz+120Hz : 120Hz Panel+120Hz Backlight
240Hz (60HZ Input) : Embedded MEMC Circuit
Touch Screen Without
Application Desktop Monitor Industrial
Signal Interface LVDS (2 ch, 8-bit) , 30 pins Connector
Input Voltage 5.0V (Typ.)
Environment Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C
