Sharp LQ104S1DG2C LCD Display

Brand Sharp

Model LQ104S1DG2C

Diagonal Size: 10.4 inch

Type a-Si TFT-LCD, LCM

Pixel Format 800(RGB)×600  [SVGA]  96PPI

Configuration RGB Vertical Stripe

Active Area 211.2(H)×158.4(V) mm

Outline Dim 246.5(H)×179.3(V) ×11(D) mm

Bezel Area 214.6(H)×162.4(V) mm

Treatment Antiglare, Hard coating (3H)

Luminance 350 cd/m² (Typ.)

Contrast Ratio 500:1 (Typ.) (TM)

View Direction 6 o'clock

Response Time 35 (Typ.)(Tr+Td)

Viewing Angle 70/70/50/60 (Typ.)(CR≥10) Left / Right / Up / Down

Operating Mode TN, Normally White, Transmissive

Support Color 262K  Light Source

WLED , 50K hours , With LED Driver

Weight 550g (Typ.)

Designed For Industrial

Frame Rate 60HzTouch PanelWithout

Interface Type Parallel RGB (1 ch, 6-bit) , 41 pins Connector

Power Supply 3.3V (Typ.)

Environment Operating Temperature: -30 ~ 80 °C ; Storage Temperature: -30 ~ 80 °C
