NIEC PCH1008 IGBT Module

Manufacturer Part Number: PCH1008Part Life Cycle Code: ActiveIhs Manufacturer: KYOCERA CORPHTS Code: 8541.30.00.80Manufacturer: KYOCERA CorporationRisk Rank: 5.22Additional Feature: UL RECOGNIZEDCase Connection: ISOLATEDConfiguration: SINGLE WITH BUILT-IN SERIES DIODEDC Gate Trigger Current-Max: 100 mADC Gate Trigger Voltage-Max: 2.5 VDesc. of Quick-Connects: 0Desc. of Screw Terminals: 0JESD-30 Code: R-XUFM-X7Non-Repetitive Pk On-state Cur: 2000 ANumber of Elements: 1Number of Terminals: 7On-state Current-Max: 100000 AOperating Temperature-Max: 125 °COperating Temperature-Min: -40 °CPackage Body Material: UNSPECIFIEDPackage Shape: RECTANGULARPackage Style: FLANGE MOUNTQualification Status: Not QualifiedRMS On-state Current-Max: 156 ARepetitive Peak Off-state Voltage: 800 VRepetitive Peak Reverse Voltage: 800 VSubcategory: Silicon Controlled RectifiersSurface Mount: NOTerminal Form: UNSPECIFIEDTerminal Position: UPPERTrigger Device Type: SCR Silicon Controlled Rectifier, 156A I(T)RMS, 100000mA I(T), 800V V(DRM), 800V V(RRM), 1 Element,
