Hitachi TX26D01VM1CAA LCD Display

Brand Hitachi

Model TX26D01VM1CAA

Diagonal Size 10.4 inch

Type a-Si TFT-LCD , LCM

Pixel Format 640(RGB)×480  [VGA]  76PPI

Configuration RGB Vertical Stripe

Active Area 211.2(H)×158.4(V) mm

Outline Dim. 243(H)×181.6(V) ×12.5(D) mm

Bezel Area 215.4(H)×162.6(V) mm

Treatment Antiglare, Hard coating (3H)

Luminance 350 cd/m² (Typ.)

Contrast Ratio 500:1 (Typ.) (TM)

Response Time 30/20 (Typ.)(Tr/Td)

Viewing Angle 50/50/50/50 (Min.)(CR≥10) Left / Right / Up / Down

Operating Mode TN, Normally White, Transmissive

IPS Family: AAS, ADS, AHVA, FFS, IPS, New Mode2, PLS, SFT, Vistarich

VA Family: ASV, HVA, MVA, PVA, SVA, UV²A, VA

Support Color 262K   63% NTSC Light Source CCFL  [2 pcs] , W/O Driver

Weight 450g (Typ.) Designed For Industrial

Frame Rate 60Hz

120Hz (60HZ Input) : Embedded MEMC Circuit

120Hz+120Hz : 120Hz Panel+120Hz Backlight

240Hz (60HZ Input) : Embedded MEMC

Circuit Touch Panel Without

Interface Type CMOS (1 ch, 6-bit) , 32 pins Connector

Power Supply 3.3V (Typ.)(VDD)

Environment Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -20 ~ 70 °C ; Vibration Level: 3.0G (29.4 m/s²)
