VICOR VI-JNZ-EX IGBT Module

Manufacturer Part Number: VI-JNZ-EX

Product Highlights

The VI-J00 MiniMod family established a new standard in component-level DC-DC converters. This “junior” size complement to the higher power VI-200 family offers up to 100 W of isolated and regulated power in a board mounted package. With thousands of input/output/power combinations, and with a maximum operating temperature rating of 100˚C, the MiniMod provides nearly unlimited flexibiliy for power system designers to meet demanding time to market requirements.

Features

• RoHS compliant (VE versions)

• Up to 100 Watts per cubic inch

• CE Marked

• Up to 90% efficiency

• Size: 2.28" x 2.4" x 0.5" (57,9 x 61,0 x 12,7)

• Remote sense and current limit

• Logic disable

• Wide range output adjust

• ZCS power architecture

• Low noise FM control

• Isolated output

Maximum ratings and characteristics

.Absolute maximum ratings (Tc=25°C unless without specified)

Input Voltage VGES:48V

Output Voltage Vces:2V

Collector current Ic Continuous Tc=25°C :15A

Collector current Icp 1ms Tc=25°C :30A

Collector power dissipation Pc:75W

Operating junction temperature Tj:-10~+100°C

Storage temperature Tstg :-20 to +105°C
