Vishay VSKDL240-14S20 IGBT Module

FEATURES

• Fast recovery time characteristics

• Electrically isolated base plate

• Industrial standard package

• Simplified mechanical designs, rapid assembly

• High surge capability

• Large creepage distances

• 3000 VRMS isolating voltage

• UL E78996 approved

• Lead (Pb)-free

• Designed and qualified for industrial level

DESCRIPTION

The VSK.L240 Series of MAGN-A-PAKs uses fastrecovery power diodes in four basic configurations. The

semiconductors are electrically isolated from the metal base,allowing common heatsinks and compact assemblies to be built. Application includes power supplies, battery chargers,welders, motor controls and general industrial current rectification. These modules are intended for those applications where fast recove

ry characteristics are required.

Absolute maximum ratings (Tc=25°C unless without specified)

Collector-Emitter voltage Vces:1400V

Gate-Emitter voltage VGES:±20V

Collector current Ic Continuous Tc=25°C :240A

Collector current Icp 1ms Tc=25°C :480A

Collector power dissipation Pc:0.125KW

Isolation Voltage VIsol (AC 1 minute) :3000V

Operating junction temperature Tj:+150°C

Storage temperature Tstg :-40 to +125°C

Mounting screw torque 4~10 N·m

Weight 850g
